SKU DH-PFS4226-24ET-360
พร้อมส่งจัดส่งภายใน 3-5 วันทำการก่อน VAT
รวม VAT 7% ฿8,977.30
แบบ: มาตรฐาน
| Layer | Layer 2 |
|---|---|
| Managed | Yes |
| Switching Capacity | 8.8 Gbps |
| Packet Forwarding Rate | 6.55 Mpps |
| Packet Buffer Memory | 2.75 Mbit |
| MAC Table Size | 4K |
| Communication Standard | IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE 802.3ab; |
| IEEE 802.3z | |
| Standard Power Supply | Yes |
| PoE | Yes |
| Ethernet Port | 24 |
| Optical Port | 2 |
| Ethernet Port Rate | 100 Mbps |
| Optical Port Rate | 1 Gbps |
| Number of Bussiness Card Slots | Port 1-24: 24 × RJ-45 10 M/100 M (PoE) |
| Port 25-26 | 2 × RJ-45 10 M/100 M/1000 M (uplink) |
| Port 25-26 | 2 × SFP 1000 M (uplink) (combo) |
| Debugging | Console × 1 |
| Power Supply | 100V–240V AC |
| Operating Temperature | –10 °C to +55 ° (14 °F to 131 °F) |
| Operating Humidity | 10% RH–90% RH |
| Power Consumption | Idling: 10W |
| Full load | 360W |
| PoE Standard | IEEE802.3af/ IEEE802.3at/ Hi-PoE/IEEE802.3bt |
| PoE Budget | Port 1-2 ≤ 90W, Port 3-24 ≤ 30W, total ≤ 360W |
| PoE Pin Assignment | 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) |
| PoE Management | Power consumption management |
| Power on and power off | |
| Power down for overload | |
| Green PoE | |
| Legacy support | |
| Long Distance PoE Transmission | 250 m long-distance power supply |
| Spanning Tree Protocol | IEEE 802.1d (STP); 802.1w (RSTP) |
| VLAN | IEEE802.1q Standard VLAN |
| Flow Control | Support IEEE 802.3x (full duplex flow control) and back pressure flow control (half duplex) |
| Link Aggregation | Static; LACP |
| Port Mirroring | One-to-one; multiple-to-one |
| Multicast | GMP snooping based on port |
| DHCP | DHCP client |
| Security | Hardware supports IP and MAC binding based on port, MAC filtering based on port, and IEEE802.1x port authentication |
| QoS | High and low priority |
| WRR | |
| 802.1P | |
| DSCP | |
| Priority based on protocol | |
| ESD | Air discharge: 8kV |
| Contact discharge | 6kV |
| Thunder-proof | Common mode: 4kV |
| Differential mode | 2kV |
| Dimensions | 440 mm × 300 mm × 44 mm (17.32″ × 11.81″ × 1.73″) (L × W × H) |
| Packaging Dimensions | Packing box: 527 mm × 412 mm × 110 mm (20.75″ × 16.22″ × 4.33″) (L × W × H) |
| Protective box | 584 mm × 549 mm × 446 mm (22.99″ × 21.61″ × 17.56″) (L × W × H) |
| Cable(m) | Load Capacity(W) · Bandwidth(Mbps) |
| 100 | 71.3 · 100 |
| 150 | 62 · 10 |
| 200 | 51 · 10 |
| 250 | 40 · 10 |
| 100 | 53 · 100 |
| 150 | 50 · 10 |
| 200 | 47 · 10 |
| 250 | 37 · 10 |
| 100 | 25.5 · 100 |
| 150 | 25.5 · 10 |
| 200 | 25.5 · 10 |
| 250 | 25.5 · 10 |
| รหัสสินค้า (SKU) | DH-PFS4226-24ET-360 |
| หมวดหมู่ | สวิตช์ PoE สำหรับกล้อง |
| ประเภทการจัดส่ง | จัดส่งสินค้าจริง |
