SKU ITX-DAHUA-DH-IPC-HFW1230TL-A-IL
จัดส่งภายใน 3-5 วันทำการรบกวนติดต่อสอบถามก่อนสั่งซื้อ
แบบ: มาตรฐาน
ยังไม่มีรายละเอียดสินค้าเพิ่มเติม
| Image Sensor | 1/2.8″ CMOS |
|---|---|
| Max. Resolution | 1920 (H) × 1080 (V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.005 lux@F1.6 (Color,30 IRE) |
| 0.0005 lux@F1.6 (B/W,30 IRE) | |
| 0 lux (Illuminator on) | |
| S/N Ratio | > 56 dB |
| Illumination Distance | Up to 30 m (98.43 ft) (IR LED) |
| Up to 30 m (98.43 ft) (Warm light) | |
| Illuminator On/Off Control | Auto;Manual |
| Illuminator Number | 2 (IR LED); 2 (Warm light) |
| Angle Adjustment | Pan: 0°–360° |
| Tilt | 0°–90° |
| Rotation | 0°–360° |
| Lens Type | Fixed-focal |
| Lens Mount | M12 |
| Focal Length | 2.8 mm;3.6 mm |
| Max. Aperture | F1.6 |
| Field of View | 2.8 mm: H: 104°; V: 55°; D: 124° |
| 3.6 mm | H: 88°; V: 44°; D: 105° |
| Iris Control | Fixed |
| Close Focus Distance | 2.8 mm: 0.8 m (2.62 ft) |
| 3.6 mm | 1.3 m (4.27 ft) |
| DORI Distance | Lens · Detect · Observe · Recognize · Identify |
| 2.8 mm | 44.1 m |
| (144.69 ft) · 17.7 m | |
| (58.07 ft) · 8.8 m | |
| (28.87 ft) · 4.4 m | |
| (14.44 ft) | |
| 3.6 mm | 58.9 m |
| (193.24 ft) · 23.6 m | |
| (77.43 ft) · 11.8 m | |
| (38.71 ft) · 5.9 m | |
| (19.36 ft) | |
| Human Detection | Support the classification and accurate detection of human |
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| Video Frame Rate | Main stream: 1920 × 1080@(1–25/30 fps) |
| Sub stream | 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. | |
| Stream Capability | 2 streams |
| Resolution | 1080p (1920 ×1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps–4096 kbps |
| H.265 | 12 kbps–4096 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | DWDR |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto;Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Built-in MIC | Yes, built-in Mic |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Alarm Event | Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; SMD (human); security exception |
| Network Port | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P |
| Interoperability | ONVIF (Profile S; Profile T); CGI |
| User/Host | 6 (Total bandwidth: 24 M) |
| Storage | FTP |
| Browser | IE; Chrome; Firefox |
| Management Software | Smart PSS Lite; DSS; DMSS |
| Mobile Client | iOS;Android |
| Cyber Security | Configuration encryption;Trusted execution;Digest;Security logs;HTTPS;Trusted upgrade;WSSE;Trusted boot;Account lockout;Generation and importing of X.509 certification;Video encryption |
| Certifications | CE-LVD: EN62368-1 |
| CE-EMC | Electromagnetic Compatibility Directive 2014/30/EU |
| Power Supply | 12 VDC/PoE (802.3af) |
| Power Consumption | Basic: 1.8 W (12 VDC); 2.3 W (PoE) |
| Max. (H.265 + intelligence on+ WDR + illuminator intensity) | 6.3 W (12 VDC); 7.8 W (PoE) |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity | ≤95% |
| Protection | IP67 |
| Casing Material | Metal+plastic |
| Product Dimensions | 197.9 mm × 80.2 mm × 76.2 mm (7.79″ × 3.16″ × 3.00″) (L × W × H) |
| Net Weight | 0.31 kg (0.68 lb) |
| Gross Weight | 0.45 kg (0.99 lb) |
| รหัสสินค้า (SKU) | ITX-DAHUA-DH-IPC-HFW1230TL-A-IL |
| หมวดหมู่ | กล้อง IP |
| ประเภทการจัดส่ง | จัดส่งสินค้าจริง |
