SKU ITX-TP-LINK-SG2428P-JETSTREAM-28
พร้อมส่งจัดส่งภายใน 3-5 วันทำการก่อน VAT
รวม VAT 7% ฿7,704.00
แบบ: มาตรฐาน
ยังไม่มีรายละเอียดสินค้าเพิ่มเติม
| Interface | • 16× 10/100/1000 Mbps PoE+ RJ45 Ports (Auto Negotiation/Auto MDI/MDIX) |
|---|---|
| • 2× Gigabit SFP Slots | |
| Fan Quantity | Fanless Design |
| Physical Security Lock | √ |
| Power Supply | 100-240V AC, 50/60Hz |
| PoE Ports (RJ45) | • Standard: 802.3at/af compliant |
| • PoE+ Ports | 16 Ports (up to 30 W PoE Output per Port) |
| • PoE Power Budget | 150 W* |
| Dimensions ( W x D x H ) | 17.3×7.1×1.7 in (440×180×44 mm) |
| Mounting | Rack Mountable |
| Switching Capacity | 36 Gbps |
| Packet Forwarding Rate | 26.78 Mpps |
| MAC Address Table | 8K |
| Packet Buffer Memory | 4.1 Mbit |
| Jumbo Frame | 9 KB |
| Quality of Service | • 802.1p CoS/DSCP priority |
| • 8 priority queues | |
| • Priority Schedule Mode | |
| – SP (Strict Priority) | |
| – WRR (Weighted Round Robin) | |
| • Queue Weight Config | |
| • Bandwidth Control | |
| – Port/Flow based Rating Limit | |
| • Smoother Performance | |
| • Storm Control | |
| – Multiple Control Modes(kbps/ratio) | |
| – Broadcast/Multicast/Unknown-Unicast Control | |
| L2 and L2+ Features | • 32 IP Interfaces: Support IPv4/IPv6 Interface |
| • Static Routing | 32 IPv4/IPv6 Static Routes |
| • DHCP Server | |
| • DHCP Relay | |
| – DHCP Interface Relay | |
| – DHCP VLAN Relay | |
| • DHCP L2 Relay | |
| • Static ARP | |
| • Proxy ARP | |
| • Gratuitous ARP | |
| • Link Aggregation | |
| • Spanning Tree Protocol | |
| • Loopback Detection | |
| • 802.3x Flow Control | |
| • Mirroring | |
| • Device Link Detect Protocol (DLDP) | |
| • 802.1ab LLDP/ LLDP-MED | |
| L2 Multicast | • 511 IPv4, IPv6 shared multicast groups |
| • IGMP Snooping | |
| • Multicast VLAN Registration (MVR) | |
| • Multicast Filtering | |
| • Limited IP Multicast (256 profiles and 16 entries per profile) | |
| Advanced Features | • Automatic Device Discovery † |
| • Batch Configuration † | |
| • Batch Firmware Upgrading † | |
| • Intelligent Network Monitoring † | |
| • Abnormal Event Warnings † | |
| • Unified Configuration † | |
| • Reboot Schedule † | |
| VLAN | • VLAN Group |
| – Max. 4K VLAN Groups | |
| • 802.1Q tag VLAN | |
| • MAC VLAN | 12 Entries |
| • Protocol VLAN | |
| • GVRP | |
| • Voice VLAN | |
| Access Control List | • Support up to 230 entries |
| • Time-based ACL | |
| • MAC ACL | |
| • IP ACL | |
| • IPv6 ACL | |
| • Combined ACL | |
| • Rule Operation | Permit/Deny |
| • Policy Action | |
| – Mirroring | |
| – Redirect | |
| – Rate Limit | |
| – QoS Remark | |
| • ACL Rules Binding | |
| – Port Binding | |
| – VLAN Binding | |
| IPv6 | • IPv6 Static Routing and ACL |
| • IPv6 Dual IPv4/IPv6 | |
| • IPv6 Interface | |
| • Multicast Listener Discovery (MLD) Snooping | |
| • IPv6 neighbor discovery (ND) | |
| • Path maximum transmission unit (MTU) discovery | |
| • Internet Control Message Protocol (ICMP) version 6 | |
| • TCPv6/UDPv6 | |
| • IPv6 applications | DHCPv6 Client, Ping6, Tracert6, Telnet(v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP |
| MIBs | • MIB II (RFC1213) |
| • Bridge MIB (RFC1493) | |
| • P/Q-Bridge MIB (RFC2674) | |
| • Radius Accounting Client MIB (RFC2620) | |
| • Radius Authentication Client MIB (RFC2618) | |
| • Remote Ping, Traceroute MIB (RFC2925) | |
| • Support TP-Link private MIBs | |
| • RMON MIB(RFC1757, rmon 1,2,3,9) | |
| Omada App | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | • Omada Cloud-Based Controller |
| • Omada Hardware Controller | |
| • Omada Software Controller | |
| Cloud Access | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller |
| Management Features | • Web-based GUI |
| • Command Line Interface (CLI) through telnet | |
| • SNMPv1/v2c/v3 | |
| • SNMP Trap/Inform | |
| • RMON (1,2,3,9 groups) | |
| • SDM Template | |
| • DHCP/BOOTP Client | |
| • Dual Image, Dual Configuration | |
| • CPU Monitoring | |
| • Cable Diagnostics | |
| • EEE | |
| • SNTP | |
| • System Log | |
| Certification | CE, FCC, RoHS |
| Package Contents | • SG2218P |
| • Power Cord | |
| • Installation Guide | |
| • Rackmount Kit | |
| • Rubber Feet | |
| System Requirements | Microsoft® Windows® XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment | • Operating Temperature: 0–45 ℃ (32–113 ℉); |
| • Storage Temperature | -40–70 ℃ (-40–158 ℉) |
| • Operating Humidity | 10–90% RH non-condensing |
| • Storage Humidity | 5–90% RH non-condensing |
| รหัสสินค้า (SKU) | ITX-TP-LINK-SG2428P-JETSTREAM-28 |
| หมวดหมู่ | สวิตช์ |
| ประเภทการจัดส่ง | จัดส่งสินค้าจริง |
