รบกวนติดต่อสอบถามก่อนสั่งซื้อ
แบบ: มาตรฐาน
ยังไม่มีรายละเอียดสินค้าเพิ่มเติม
| Interface | • 24× 10/100/1000 Mbps RJ45 Ports |
|---|---|
| • 4× 10G SFP+ Slots | |
| • 2× USB 2.0 Ports | |
| • 1× RJ45 Console Port | |
| • 1× USB Type-C Console Port | |
| • 1× RJ45 Management Port | |
| Fan Quantity | Four Internal Fixed Fans |
| Power Supply | Two Internal Fixed Power Supply Modules (100–240 VAC, 50/60 Hz) |
| Dimensions ( W x D x H ) | 17.3 × 15.0 × 1.7 in (440 × 380 × 44 mm) |
| Mounting | Rackmountable |
| Max Power Consumption | 28.4 W (220 V/50 Hz) |
| Max Heat Dissipation | 96.91 BTU/hr (220 V/50 Hz) |
| Switching Capacity | 128 Gbps per Unit |
| Stacking | • Stacking Number: 4 |
| • Stacking Port | 10G SFP+ Slot (all uplink ports can be used as stacking ports) |
| • Stack Bandwidth | 20 Gbps Per Port (Full-Duplex) |
| Packet Forwarding Rate | 95.2 Mpps |
| MAC Address Table | 32 K |
| Packet Buffer Memory | 3 MB |
| Jumbo Frame | 9 KB |
| Quality of Service | • Class of Service |
| – 8 Queues of Priority | |
| – Port Priority | |
| – IEEE 802.1p Priority | |
| – DSCP Priority | |
| – Queue Min-Bandwidth | |
| – Schedule Mode (SP, WRR, SP+WRR) | |
| • Bandwidth Control | |
| – Rate Limit | |
| – Storm Control | |
| • Voice VLAN | |
| • User-Defined OUI | |
| • Smoother Performance | |
| • Action for Flows | |
| – QoS remark (802.1P Remark, DSCP Remark) | |
| L2 and L2+ Features | • Link Aggregation |
| • Spanning Tree Protocol | |
| • Port-based and VLAN-based Loopback Detection | |
| • 802.3x Flow Control | |
| • Supports 2,048 IGMP groups | |
| • ERPS | |
| • Mirroring | |
| • RSPAN | |
| • MAC Address Table | |
| • PIM-DM (IPv4) | |
| • Multicast | |
| – IGMP Snooping | |
| – MLD Snooping | |
| – L2 Multicast Table | |
| – Fast Leave | |
| – Multicast VLAN Registration (MVR) | |
| – Static Multicast IP | |
| – Multicast Filtering | |
| Advanced Features | • Automatic Device Discovery † |
| • Batch Configuration † | |
| • Batch Firmware Upgrading † | |
| • Intelligent Network Monitoring † | |
| • Abnormal Event Warnings † | |
| • Unified Configuration † | |
| • 802.3ah Ethernet Link OAM | |
| • L2PT (Layer 2 Protocol Tunneling) | |
| • Device Link Detect Protocol (DLDP) | |
| • DDM | |
| • sFlow | |
| VLAN | • Max 4K VLAN Group (802.1q VLAN) |
| • 802.1Q Tagged VLAN | |
| • MAC VLAN Entries | 200 |
| • Multicast VLAN | |
| • Management VLAN | |
| • VLAN VPN (QinQ) | Max 256 entries |
| • GVRP | |
| • Protocol VLAN | Protocol Template 16, Protocol VLAN 12 entries |
| • VLAN VPN | |
| • Voice VLAN | |
| • Private VLAN | |
| Omada App | Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | • Omada Cloud-Based Controller |
| • Omada Hardware Controller | |
| • Omada Software Controller | |
| Cloud Access | Yes. Requiring the use of the Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requiring the use of the Omada Cloud-Based Controller. |
| Management Features | • Web-based GUI |
| • Command Line Interface (CLI) through console port, telnet | |
| • SNMPv1/v2c/v3 | |
| – Trap/Inform | |
| – RMON (1, 2, 3, 9 groups) | |
| • SDM Template | |
| • DHCP/BOOTP Client | |
| • 802.1ab LLDP/LLDP-MED | |
| • DHCP Auto Install | |
| • Dual Image, Dual Configuration | |
| • CPU Monitoring | |
| • Cable Diagnostics | |
| • Password Recovery | |
| • SNTP | |
| • System Log | |
| • EEE | |
| Package Contents | • SG6428X Switch |
| • 2× Power Cords | |
| • RJ45 Console Cable | |
| • Quick Installation Guide | |
| • Rackmount Kit | |
| • Rubber Feet | |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment | • Operating Temperature: 0–45 ℃ (32–113 ℉); |
| • Storage Temperature | -40–70 ℃ (-40–158 ℉) |
| • Operating Humidity | 10–90% RH non-condensing |
| • Storage Humidity | 5–90% RH non-condensing |
| หมวดหมู่ | สวิตช์ |
| ประเภทการจัดส่ง | จัดส่งสินค้าจริง |
