SKU VIGI NVR2016H
พร้อมส่งจัดส่งภายใน 3-5 วันทำการก่อน VAT
รวม VAT 7% ฿4,815.00
แบบ: มาตรฐาน
ยังไม่มีรายละเอียดสินค้าเพิ่มเติม
| IP Video Input | 16-Channel |
|---|---|
| Incoming Bandwidth | 160 Mbps |
| Outgoing Bandwidth | 160 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840×2160/30Hz, 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz |
| Video Output Mode | HDMI/VGA Independent Output |
| Multi-View Display | 1/4/6/8/9/16 |
| Audio Compression | G.711A/G.711U/G.726 |
| Video Compression | H.265+/H.265/H.264+/H.264 |
| Record Resolution | 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous Playback | 16-Channel † |
| Capability | • 25fps： |
| 10-ch@1080P | |
| 2-ch@8MP、4-ch@5MP、5-ch@4MP、6-ch@3MP | |
| Record Mode | • Manual Recording |
| • Scheduling Recording | |
| • Motion Detection Recording | |
| Playback Mode | • Instant Playback |
| • Regular Playback | |
| • Tag Playback | |
| • Event Playback | |
| Backup Mode | • Regular Backup |
| • Video Clip Backup | |
| Playback Function | • Play |
| • Pause | |
| • Stop | |
| • Fast Forward | |
| • Fast Backward | |
| • Play By Frame | |
| • Full Screen | |
| • Video Clip | |
| • Export Clip | |
| • Digital Zoom | |
| • Lock Recording | |
| • Audio On/Off | |
| Protocol | UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP |
| Mobile Phone Access | Android, iOS |
| Web Browser | Chrome (57+), Firefox (52+), Edge (91+), Safari (11+) |
| Interoperability | ONVIF Profile S, CGI |
| Network Interface | 1, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface |
| USB Interface | 1 Front USB 2.0 Port, 1 Rear USB 3.0 Port |
| Audio Interface | 1-ch RCA Input; 1-ch RCA Output |
| Alarm In/Out | 6/4 |
| Serial Interface | N/A |
| Power | 1× DC Jack |
| Reset Button | 1 |
| Speaker | N/A |
| eSATA | 1* |
| HDMI | 1 |
| VGA | 1 |
| SATA | 2 SATA Interfaces |
| Capacity | Up to 16 TB Capacity for Each HDD* |
| General Alarm | • Motion Detection |
| • Video Tampering | |
| • Scene Change Detection | |
| • Line-Crossing Detection | |
| • Intrusion Detection | |
| • Region Entering Detection | |
| • Region Exiting Detection | |
| • Loitering Detection | |
| • Object Abandoned/Removal Detection | |
| • Vehicle Detection | |
| • Human Detection | |
| • Abnormal Sound Detection | |
| • Smart Frame | |
| Note | The alarm function requires the use of a camera. |
| Anomaly Alarm | • Video Loss |
| • Offline and IP Conflict | |
| • Disk Exception | |
| • Login Exception | |
| • Fan Exception | |
| Note | The alarm function requires the use of a camera. |
| Alarm Linkage | • Recording |
| • White Light Alarm | |
| • Buzzer | |
| • Log | |
| • Audible Alarm | |
| Note | The alarm function requires the use of a camera. |
| Storage Temperature | -40–70 °C |
| Storage Humidity | 10%~90% RH Non-Condensing |
| Package Content | • VIGI Network Video Recorder |
| • Power Adapter | |
| • HDD Power Cable | |
| • HDD Data Cables | |
| • Mounting Accessories | |
| • Mouse | |
| • Quick Installation Guide | |
| Working Temperature | • NVR: -10–55 °C |
| • Power Adapter | 0–40 °C |
| Working Humidity | 10%~90% RH Non-Condensing |
| Dimensions( W X D X H ) | 13.0 × 11.2 × 1.8 in (330 × 285 × 45 mm) |
| Net Weight | 2.0 Kg # |
| Gross Weight | 3.3 Kg # |
| Power Supply | 12V DC/3.3A |
| Max. Power Consumption | • 7.475 W (Without Disk) |
| • 28.635 W (With Disk) | |
| Certifications | CE, NTRA, Triman, BSMI, VCCI, FCC, HDMI, ONVIF |
| รหัสสินค้า (SKU) | VIGI NVR2016H |
| หมวดหมู่ | เครื่องบันทึก NVR/DVR |
| ประเภทการจัดส่ง | จัดส่งสินค้าจริง |
