SKU ES206GP
พร้อมส่งจัดส่งภายใน 3-5 วันทำการก่อน VAT
รวม VAT 7% ฿1,808.30
แบบ: มาตรฐาน
ยังไม่มีรายละเอียดสินค้าเพิ่มเติม
| Interface | • 6× 10/100/1000 Mbps RJ45 Ports (Ports 1–4 Support 802.3af PoE and 802.3at PoE+) |
|---|---|
| • Auto-Negotiation/Auto MDI/MDIX | |
| Fan Quantity | Fanless |
| Installation | • Desktop |
| • Wall Mount | |
| Physical Security Lock | √ |
| Power Supply | DC Power Adapter (Output: 53.5VDC / 1.31A) |
| PoE Ports (RJ45) | • Standard: 802.3af PoE and 802.3at PoE+ compliant |
| • PoE Ports | 4 ports |
| • PoE Budget | 65W available for all PoE+ ports, 30W max per port |
| • Fast PoE & Perpetual PoE | |
| • PoE Auto Recovery ‡ | |
| • Up to 250m PoE transmission distance** | |
| Dimensions ( W x D x H ) | 6.2 × 4.0 × 1.0 in (158 × 101 × 25 mm) |
| Surge Protection | ±6kV |
| Switching Capacity | 12 Gbps |
| Packet Forwarding Rate | 7.4 Mpps |
| MAC Address Table | 8K |
| Packet Buffer Memory | 4 Mbit |
| Jumbo Frame | 15 KB |
| Quality of Service | • Port-based/802.1p/DSCP QoS |
| • 8 Priority Queues | |
| • Priority Schedule Mode | |
| – WRR (Weighted Round Robin) | |
| • Queue Weight Config | |
| • Bandwidth Control | |
| – Port-Based Rating Limit | |
| • Storm Control | |
| – Multiple Control Modes (kbps/pps) | |
| – Broadcast/Multicast/Unknown-Unicast Control △ | |
| L2 Features | • Static Link Aggregation |
| • Loop Prevention / Loopback Detection | |
| • Flow Control | |
| – 802.3x Flow Control | |
| • Mirroring | |
| – Port Mirroring | |
| – One-to-One | |
| – Many-to-One | |
| – Ingress/Egress/Both | |
| • Port Statistics | |
| – Port Mirror Status | |
| – Traffic Statistics | |
| • 802.1ab LLDP | |
| L2 Multicast | • IGMP Snooping |
| – IGMP v1/v2/v3 Snooping | |
| – Fast Leave | |
| VLAN | • MTU VLAN |
| • Port-Based VLAN | |
| • 802.1Q Tag VLAN | |
| – Max 32 VLAN Groups | |
| – 4K VID | |
| Transmission Method | Store-And-Forward |
| Omada App | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | • Omada Cloud-Based Controller |
| • Omada Hardware Controller | |
| • Omada Software Controller | |
| Cloud Access | Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requires the use of Omada Cloud-Based Controller |
| Management Features | • Web-based GUI |
| • DHCP Client | |
| • Cable Diagnostics | |
| • Automatic Device Discovery † | |
| • Batch Configuration † | |
| • Batch Firmware Upgrading † | |
| • Unified Configuration † | |
| Certification | FCC, CE, RoHS |
| Package Contents | • ES206GP |
| • Power Adapter | |
| • Power Cord | |
| • Rubber Feet | |
| • Installation Guide | |
| Environment | • Operating Temperature: -5℃~40℃ (23℉~104℉) |
| • Storage Temperature | -40℃~70℃ (-40℉~158℉) |
| • Operating Humidity | 10%~90% non-condensing |
| • Storage Humidity | 5%~90% non-condensing |
| รหัสสินค้า (SKU) | ES206GP |
| หมวดหมู่ | สวิตช์ |
| ประเภทการจัดส่ง | จัดส่งสินค้าจริง |
