SKU ITX-TP-LINK-SG1218MP-18-PORT-GIG
พร้อมส่งจัดส่งภายใน 3-5 วันทำการก่อน VAT
รวม VAT 7% ฿6,313.00
แบบ: มาตรฐาน
LINE ขอใบเสนอราคา @ITERNIXยังไม่มีรายละเอียดสินค้าเพิ่มเติม
| Standards and Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3af, IEEE 802.3at, IEEE 802.1q, IEEE 802.1p |
|---|---|
| Interface | • 16× PoE+ gigabit RJ45 ports |
| • 2× gigabit non-PoE RJ45 ports | |
| • 2× combo gigabit SFP slots | |
| Network Media | • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) |
| • EIA/TIA-568 100Ω STP (maximum 100m) | |
| • 100BASE-TX | UTP category 5, 5e cable (maximum 100m) |
| • EIA/TIA-568 100Ω STP (maximum 100m) | |
| • 1000BASE-T | UTP category 5, 5e, 6 or above cable (maximum 100m) |
| • EIA/TIA-568 100Ω STP (maximum 100m) | |
| • 1000BASE-X MMF, SMF | |
| Fan Quantity | 2 |
| Physical Security Lock | Yes |
| Power Supply | 100–240 VAC, 50/60 Hz |
| PoE+ Ports(RJ45) | • Standard: 802.3at/802.3af compliant |
| • PoE Ports | Ports 1–16 |
| • PoE Power Budget | 250 W |
| Dimensions ( W x D x H ) | 17.3 × 7.1 × 1.73 in (440 × 180 × 44 mm) |
| Mounting | Rack Mountable |
| Max Power Consumption | • 19 W (220/50 Hz. no PD connected) |
| • 293.34 W (220/50 Hz. with 250 W PD connected) | |
| Max Heat Dissipation | • 64.79 BTU/h (no PD connected) |
| • 1000.29 BTU/h (with 250 W PD connected) | |
| Switching Capacity | 36 Gbps |
| Packet Forwarding Rate | 26.78 Mbps |
| MAC Address Table | 8K |
| Packet Buffer Memory | 4.1 Mbit |
| Advanced Functions | • Compatible With IEEE 802.3af/at Compliant PDs |
| • 802.1p/DHCP QoS | |
| • Mac Address Auto-Learning And Auto-Aging | |
| • IEEE802.3x Flow Control For Full-Duplex Mode And Backpressure For Half-Duplex Mode | |
| • Extend Mode (Ports 1–4, Up to 250 m PoE power supply and data transmission) | |
| • Priority Mode (Ports 1–4) | |
| • Isolation Mode (Ports 1-8/9-16) | |
| • PoE Auto Recovery (Ports 1-16) | |
| Jumbo Frame | 10 KB |
| Certification | CE, FCC, RoHS |
| Package Contents | • TL-SG1218MP |
| • Installation Guide | |
| • Power Cord | |
| • Rackmount Kit | |
| • Rubber Feet | |
| Environment | • Operating Temperature: 0–50 °C (32–122 °F) |
| • Storage Temperature | -40–70 °C (-40–158 °F) |
| • Operating Humidity | 10–90% RH non-condensing |
| • Storage Humidity | 5–90% RH non-condensing |
| รหัสสินค้า (SKU) | ITX-TP-LINK-SG1218MP-18-PORT-GIG |
| หมวดหมู่ | สวิตช์ |
| ประเภทการจัดส่ง | จัดส่งสินค้าจริง |
