SKU ITX-TP-LINK-SG3452XMPP-OMADA-48-
พร้อมส่งจัดส่งภายใน 3-5 วันทำการก่อน VAT
รวม VAT 7% ฿30,923.00
แบบ: มาตรฐาน
ยังไม่มีรายละเอียดสินค้าเพิ่มเติม
| Interface | • 48× 10/100/1000 Mbps RJ45 Ports (8× PoE++, 40× PoE+) |
|---|---|
| • 4× 10G SFP+ Slots | |
| • 1× RJ45 Console Port | |
| • 1× Micro-USB Console Port | |
| Fan Quantity | 3 |
| Physical Security Lock | √ |
| Power Supply | 100-240 V AC~50/60 Hz |
| PoE Ports (RJ45) | • Standard: 802.3at/af/bt compliant |
| • PoE++ Ports | Ports 1~8 (up to 90 W PoE Output per Port) |
| • PoE+ Ports | Ports 9~48 (up to 30 W PoE Output per Port) |
| • Power Budget | 750 W* |
| Dimensions ( W x D x H ) | 17.3×13.0×1.7 in (440×330×44 mm) |
| Mounting | Rack Mountable |
| Max Power Consumption | • 913.4 W (110V/60Hz) ( with 750 W PD connected) |
| Max Heat Dissipation | • 3114.69 BTU/hr (110 V/60 Hz) (with 750 W PD connected) |
| Switching Capacity | 176 Gbps |
| Packet Forwarding Rate | 130.9 Mpps |
| MAC Address Table | 16 K |
| Packet Buffer Memory | 12 Mbit |
| Jumbo Frame | 9 KB |
| Quality of Service | • 8 priority queues |
| • 802.1p CoS/DSCP priority | |
| • Queue scheduling | SP (Strict Priority), WRR (Weighted Round Robin), SP+WRR |
| • Bandwidth Control | Port/Flow-based Rating Limiting |
| • Smoother Performance | |
| • Action for Flows | QoS remark (802.1P Remark, DSCP Remark) |
| L2 and L2+ Features | • 128 IP Interfaces: Support IPv4/IPv6 Interface |
| • Static Routing | 48 IPv4/IPv6 Static Routes |
| • Static ARP | 128 static entries |
| • 512 ARP Entries | |
| • Proxy ARP | |
| • Gratuitous ARP | |
| • DHCP Server | |
| • DHCP Relay | DHCP Interface Relay, DHCP VLAN Relay |
| • DHCP L2 Relay | |
| • Link Aggregation | |
| • Spanning Tree Protocol | |
| • Loopback Detection | |
| • 802.3x Flow Control | |
| • Mirroring | |
| L2 Multicast | • Supports 1000 (IPv4, IPv6) IGMP groups |
| • IGMP Snooping | |
| • IGMP Authentication | |
| • Multicast VLAN Registration (MVR) | |
| • MLD Snooping | |
| • Multicast Filtering | 256 profiles and 16 entries per profile |
| Advanced Features | • Automatic Device Discovery † |
| • Batch Configuration † | |
| • Batch Firmware Upgrading † | |
| • Intelligent Network Monitoring † | |
| • Abnormal Event Warnings † | |
| • Unified Configuration † | |
| • Reboot Schedule † | |
| • L2PT (Layer 2 Protocol Tunneling) | |
| • Device Link Detect Protocol (DLDP) | |
| • PPPoE ID Insertion | |
| • ERPS | |
| • 802.3ah Ethernet Link OAM | |
| • DDM | |
| • sFlow | |
| VLAN | • VLAN Group: Max 4K VLAN Groups |
| • 802.1q Tagged VLAN | |
| • MAC VLAN | 30 Entries |
| • Protocol VLAN | Protocol Template 16, Protocol VLAN 16 |
| • Private VLAN | |
| • GVRP | |
| • VLAN VPN | VLAN Mapping, VLAN Replace |
| • Voice VLAN | |
| Access Control List | • Time-based ACL |
| • MAC ACL | Source MAC, Destination MAC, VLAN ID, User Priority, Ether Type |
| • IP ACL | Source IP, Destination IP, Fragment, IP Protocol, TCP Flag, TCP/UDP Port, DSCP/IP TOS |
| • Combined ACL | |
| • Packet Content ACL | |
| • IPv6 ACL | |
| • Policy | Mirroring, Redirect, Rate Limit, QoS Remark |
| • ACL applies to Port/VLAN | |
| IPv6 | • IPv6 Dual IPv4/IPv6 |
| • Multicast Listener Discovery (MLD) Snooping | |
| • IPv6 ACL | |
| • IPv6 Interface | |
| • Static IPv6 Routing | |
| • IPv6 neighbor discovery (ND) | |
| • Path maximum transmission unit (MTU) discovery | |
| • Internet Control Message Protocol (ICMP) version 6 | |
| • TCPv6/UDPv6 | |
| • IPv6 applications | DHCPv6 Client, Ping6, Tracert6, Telnet (v6), IPv6 SNMP, IPv6 SSH, IPv6 SSL, Http/Https, IPv6 TFTP |
| MIBs | • MIB II (RFC1213) |
| • Interface MIB (RFC2233) | |
| • Ethernet Interface MIB (RFC1643) | |
| • Bridge MIB (RFC1493) | |
| • P/Q-Bridge MIB (RFC2674) | |
| • RMON MIB (RFC2819) | |
| • RMON2 MIB (RFC2021) | |
| • Radius Accounting Client MIB (RFC2620) | |
| • Radius Authentication Client MIB (RFC2618) | |
| • Remote Ping, Traceroute MIB (RFC2925) | |
| • Support TP-Link private MIB | |
| Omada App | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | • Omada Cloud-Based Controller |
| • Omada Hardware Controller | |
| • Omada Software Controller | |
| Cloud Access | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. |
| Management Features | • Web-based GUI |
| • Command Line Interface (CLI) through console port, telnet | |
| • SNMPv1/v2c/v3 | |
| – Trap/Inform | |
| – RMON (1, 2, 3, 9 groups) | |
| • SDM Template | |
| • DHCP/BOOTP Client | |
| • 802.1ab LLDP/LLDP-MED | |
| • DHCP AutoInstall | |
| • Dual Image, Dual Configuration | |
| • CPU Monitoring | |
| • Cable Diagnostics | |
| • EEE | |
| • Password Recovery | |
| • SNTP | |
| • System Log | |
| Certification | CE, FCC, RoHS |
| Package Contents | • SG3452XMPP Switch |
| • Power Cord | |
| • Quick Installation Guide | |
| • Rackmount Kit | |
| • Rubber Feet | |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment | • Operating Temperature: 0–40 ℃ (32–104 ℉); |
| • Storage Temperature | -40–70 ℃ (-40–158 ℉) |
| • Operating Humidity | 10–90% RH non-condensing |
| • Storage Humidity | 5–90% RH non-condensing |
| รหัสสินค้า (SKU) | ITX-TP-LINK-SG3452XMPP-OMADA-48- |
| หมวดหมู่ | สวิตช์ |
| ประเภทการจัดส่ง | จัดส่งสินค้าจริง |
