| Interface | • 6× 10/25G SFP28 Slots |
|---|---|
| • 26× 1/10G SFP+ Slots | |
| • 2× USB 3.0 Ports | |
| • 1× RJ45 Console Port | |
| • 1× USB Type C Console Port | |
| • 1× RJ45 Management Port | |
| Fan Quantity | Four field-replaceable and hot-swappable fans (N+1 redundant) |
| Physical Security Lock | √ |
| Power Supply | Two field-replaceable and hot-swappable redundant power supplies (100–240 VAC, 50/60 Hz) |
| *Ships with one PSM550-AC module by default, and another field-replaceable redundant power supply requires a separate purchase. | |
| Power Consumption | 86.7 W (110 V/60 Hz) |
| Dimensions ( W x D x H ) | 17.3 × 15.0 × 1.7 in (440 × 380 × 44 mm) |
| Mounting | Rack Mountable |
| Max Heat Dissipation | 295.85 BTU/hr (110 V/60 Hz) |
| Switching Capacity | 820 Gbps |
| Stacking | • Stacking Number: 8 |
| • Stacking Port | 25G SFP28 |
| • Stack Bandwidth | Up to 300 Gbps (6 stack ports) |
| Packet Forwarding Rate | 610.1 Mpps |
| MAC Address Table | 128 K |
| Packet Buffer Memory | 8 MB |
| Jumbo Frame | 9 KB |
| Quality of Service | • Class of Service |
| – 8 Queues of Priority | |
| – Port Priority | |
| – IEEE 802.1p Priority | |
| – DSCP Priority | |
| – Queue Min-Bandwidth | |
| – Schedule Mode (SP, WRR, SP+WRR) | |
| • Bandwidth Control | |
| – Rate Limit | |
| – Strom Control | |
| • User-Defined OUI | |
| • Smoother Performance | |
| • Action for Flows | |
| – QoS remark (802.1P Remark, DSCP Remark) | |
| Advanced Features | • Automatic Device Discovery † |
| • Batch Configuration † | |
| • Batch Firmware Upgrading † | |
| • Intelligent Network Monitoring † | |
| • Abnormal Event Warnings † | |
| • Unified Configuration † | |
| • 802.3ah Ethernet Link OAM | |
| • L2PT (Layer 2 Protocol Tunneling) | |
| • Device Link Detect Protocol (DLDP) | |
| • DDM | |
| • sFlow | |
| • PPPoE ID Insertion | |
| VLAN | • VLAN Group (802.1q VLAN) |
| – Max 4K VLAN Groups | |
| • 802.1Q Tagged VLAN | |
| • MAC VLAN entries | 200 |
| • Multicast VLAN | |
| • Management VLAN | |
| • VLAN VPN (QinQ) | Max 256 entries |
| • GVRP | |
| • Protocol VLAN | Protocol Template 16, Protocol VLAN 12 entries |
| • VLAN VPN | |
| – VLAN Mapping | |
| – VLAN Replace | |
| • Voice VLAN | |
| • Private VLAN | |
| Omada App | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Centralized Management | • Omada Cloud-Based Controller |
| • Omada Hardware Controller | |
| • Omada Software Controller | |
| Cloud Access | Yes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. |
| Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. |
| Management Features | • Web-based GUI |
| • Command Line Interface (CLI) through console port, telnet | |
| • SNMPv1/v2c/v3 | |
| – Trap/Inform | |
| – RMON (1, 2, 3, 9 groups) | |
| • SDM Template | |
| • DHCP/BOOTP Client | |
| • 802.1ab LLDP/LLDP-MED | |
| • DHCP Auto Install | |
| • Dual Image, Dual Configuration | |
| • CPU Monitoring | |
| • Cable Diagnostics | |
| • Password Recovery | |
| • SNTP | |
| • System Log | |
| Package Contents | • SX6632YF Switch |
| • Power Cord | |
| • Quick Installation Guide | |
| • Rackmount Kit | |
| • Rubber Feet | |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® or Linux. |
| Environment | • Operating Temperature: |
| -5 °C to 50 °C (23 °F to 122 °F) @ 300 meters | |
| -5 °C to 45 °C (23 °F to 113 °F) @ 2,000 meters | |
| -5 °C to 40 °C (23 °F to 104 °F) @ 3,000 meters• Storage Temperature | -40 °C to 70 ℃ (-40 ℉ to 158 ℉) |
| • Operating Humidity | 10–90% RH non-condensing |
| • Storage Humidity | 5–90% RH non-condensing |
| หมวดหมู่ | สวิตช์ |
| ประเภทการจัดส่ง | จัดส่งสินค้าจริง |
