Name: TP-LINK VIGI NVR1008H 8 Channel Network Video Recorder
Brand: TP-Link

รายละเอียดสินค้า

รุ่น / SKU	VIGI NVR1008H
Web Browser	Chrome (57+), Firefox (52+), Edge (91+)
Interoperability	ONVIF Profile S, CGI
IP Video Input	8-Channel
Capacity	Up to 16 TB Capacity for Each HDD*
Storage Temperature	-40–70 °C
Storage Humidity	10%~90% RH Non-Condensing
Incoming Bandwidth	80 Mbps
Outgoing Bandwidth	60 Mbps
HDMI Output Resolution	1 Channel, Resolution: 3840 ×2160/30Hz, 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Network Interface	1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
USB Interface	2× USB 2.0
Audio Interface	1-ch RCA Input; 1-ch RCA Output
Serial Interface	N/A
HDMI	1
Audio Compression	G.711A/G.711U/G.726
Speaker	N/A
Power	1× DC Jack
Power Adapter	0–40 °C
External Power Supply	DC 12V/1.5A
Max. Power Consumption	4.25 W (without disk)
VGA Output Resolution	1 Channel, Resolution: 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz
Multi-View Display	1/4/6/8
Video Compression	H.265+/H.265/ H.264+/H.264
Record Resolution	8 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
VGA	1
Alarm In/Out	N/A
Reset Button	1
General Alarm	• Motion Detection Video Tampering Scene Change Detection Line-Crossing Detection Intrusion Detection Region Entering Detection Region Exiting Detection Loitering Detection Object Abandoned/Removal Detection Vehicle Detection Human Detection Abnormal Sound Detection Smart Frame
Anomaly Alarm	• Video Loss Offline and IP Conflict Disk Exception Login Exception
Alarm Linkage	• Recording White Light Alarm Buzzer Log Audible Alarm
Package Content	• VIGI Network Video Recorder Power Adapter HDD Screws Mouse Quick Installation Guide
Working Temperature	• NVR: -10–55 °C
Working Humidity	10%~90% RH Non-Condensing
Dimensions( W X D X H )	246.2 × 148.2 × 45 mm
Net Weight	0.59 kg
Gross Weight	0.95 kg
Certifications	CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI
Video Output Mode	HDMI/VGA Simultaneous Output
Synchronous Playback	8-Channel †
Capability	• 25fps: 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP
30fps	4-ch @ 3MP, 2-ch @ 5MP
Record Mode	• Manual Recording Scheduling Recording Motion Detection Recording
Playback Mode	• Instant Playback Regular Playback Tag Playback Event Playback
Backup Mode	• Regular Backup Video Clip Backup
Playback Function	• Play Pause Stop Fast Forward Fast Backward Play By Frame Full Screen Video Clip Export Clip Digital Zoom Lock Recording Audio On/Off
Protocol	UPnP (Plug and Play), NTP (Network Timing), SMTP, DNS, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP
Mobile Phone Access	Android, iOS
eSATA	N/A
SATA	1 SATA Interface
Note	The alarm function requires the use of a camera.
ระยะเวลารับประกัน	3 ปี
