| รุ่น / SKU | ER706W |
|---|---|
| IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
| Omada App | Yes. |
| Centralized Management |
|
| Cloud Access | Yes. |
| Zero-Touch Provisioning | Yes. Require the use of Omada Cloud-Based Controller. |
| Management Features |
|
| System Requirements |
|
| Flash | 128 MB NAND |
| DRAM | 512 MB DDR4 |
| IPsec VPN Throughput | • ESP-SHA1-AES256: 646.9Mbps |
| L2TP VPN Throughput | • Unencrypted: 1034.0 Mbps |
| PPTP VPN Throughput | • Unencrypted: 1165.0 Mbps |
| SSL VPN Throughput | 126.7Mbps |
| 66 Byte Packet forwarding rate | 1,453,489 pps / 1,453,488 pps |
| 1,518 Byte Packet forwarding rate | 81,274 pps / 91,275 pps |
| Storage Temperature | -40 °C to 70 °C (-40 °F to 158 °F) |
| Storage Humidity | 5% to 90% non-condensing |
| Wi-Fi Frequency & Signal Rate | • 2.4 GHz: 574 Mbps |
| 5 GHz | 2402 Mbps (HE160) |
| Antenna | • 2.4 GHz: 2x 3 dBi dual-band detachable antennas |
| 5 GHz | 3x 4.5 dBi dual-band detachable antennas |
| Wireless Encryption | WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3 Enterprise |
| Bandwidth Control | IP-Based Bandwidth Control |
| Interface |
|
| Guest Network | Support |
| WAN Connection Type |
|
| Power Supply | 12VDC / 2A Power Adapter |
| Max Power Consumption | • EU: 16.8W (with USB 3.0 connected), 11.8W (without USB 3.0 connected) |
| NAT(PPPoE) | 942.9 Mbps / 942.9Mbps |
| Button | Reset Button |
| VLAN | 802.1Q VLAN |
| ACL | IP/Port/Protocol/Domain Name Filtering |
| Dimensions ( W x D x H ) |
|
| Mounting | Desktop/Wall-mounting |
| NAT (Static IP) | 937.2 Mbps / 936.1Mbps |
| Certification | CE, FCC, RoHS |
| Package Contents |
|
| Environment | • Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F) |
| Operating Humidity | 10% to 90% non-condensing |
| US | 22.7W (with USB 3.0 connected) 18.2W (without USB 3.0 connected) |
| GRE | • Unencrypted: 624.2Mbps |
| Encrypted | 301.5Mbps |
| WireGuard VPN | 393.5Mbps |
| Concurrent Session | 150,000 |
| New Sessions /Second | 5,100 |
| NAT(DHCP) | 945.8 Mbps / 940.6Mbps |
| NAT (L2TP) | 837.4 Mbps / 881.5Mbps |
| NAT (PPTP) | 803.0 Mbps / 910.5 Mbps |
| ESP-SHA256-AES256 | 642.8Mbps |
| ESP-SHA384-AES256 | 648.9Mbps |
| ESP-SHA512-AES256 | 658.4 Mbps |
| OpenVPN | 129.3Mbps |
| Encrypted | 570.0 Mbps |
| Encrypted | 209.0 Mbps |
| Advanced Functions |
|
| MAC Clone | Modify WAN Address |
| DHCP |
|
| IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
| Advanced Routing |
|
| Load Balance |
|
| NAT |
|
| Session Limit | IP-Based Session Limit |
| SSL VPN | 50 Tunnels |
| IPsec VPN |
|
| PPTP VPN |
|
| L2TP VPN |
|
| OpenVPN |
|
| Filtering |
|
| ARP Inspection |
|
| Attack Defense |
|
| Access Control | Source/Destination IP Based Access Control |
| Web Authentication |
|
| Service |
|
| Maintenance |
|
| ระยะเวลารับประกัน | ตลอดอายุการใช้งาน (สิ้นสุด 3 ปีหลังผู้ผลิตประกาศหยุดผลิต) |
