SKU UQT-UDM-SE
พร้อมส่งจัดส่งภายใน 3-5 วันทำการก่อน VAT
รวม VAT 7% ฿29,425.00
แบบ: มาตรฐาน
ยังไม่มีรายละเอียดสินค้าเพิ่มเติม
| Test data – UniFi Application Suite | Full |
|---|---|
| UniFi Devices | 200+ |
| Client Devices | 200+ |
| WiFi | – |
| High Availability | Shadow Mode |
| Multi-WAN Load Balancing | Yes |
| Application-Aware Firewall | Yes |
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″) |
| Weight | 5 kg (10.9 lb) |
| Enclosure material | Aluminium CNC, SGCC steel |
| Mount material | SGCC steel |
| Processor | Quad-core ARM® Cortex®-A57 at 1.7 GHz |
| System memory | 4 GB DDR4 |
| On-board storage | 16 GB eMMC |
| Integrated 128 GB SSD | |
| Management interface | Ethernet |
| Bluetooth | |
| Networking interface | LAN: |
| (8) GbE RJ45 ports | |
| (1) 2.5 GbE RJ45 port | |
| (1) 10G SFP+ port | |
| PoE interface | (6) PoE (Pair A 1, 2+; 3, 6-) |
| (2) PoE+ (Pair A 1, 2+; 3, 6-) | |
| IDS/IPS throughput | 3.5 Gbps* |
| *Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation. | |
| Power method | (1) Universal AC input, 100—240V AC, 4.4A Max., 50/60 Hz |
| (1) USP-RPS DC input, 52V DC, 3.94A | |
| Power supply | AC/DC, internal, 240W |
| Supported voltage range | 100—240V AC |
| Max. power consumption | 50W (Excluding PoE output) |
| PoE budget | 180W |
| Max. PoE wattage per port by PSE | PoE: 15.4W |
| PoE+ | 30W |
| Voltage range PoE mode | PoE: 44—57V |
| PoE+ | 50—57V |
| ESD/EMP protection | Air: ± 15kV, contact: ± 8kV |
| LCM display | (1) 1.3″ touchscreen |
| Button | Factory reset |
| Ambient operating temperature | -10 to 40° C (14 to 104° F) |
| Ambient operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| Performance | Redundant WAN with failover and load balancing |
| WiFi QoS with UniFi APs | |
| Application, domain, and country-based QoS | |
| Application and device type identification | |
| Additional internet failover with LTE Backup | |
| Internet quality and outage reporting | |
| Next-generation security | Application-aware firewall rules |
| Signature-based IPS/IDS threat detection | |
| Content, country, domain, and ad filtering | |
| VLAN/subnet-based traffic segmentation | |
| Full stateful firewall | |
| Advanced networking | License-free SD-WAN |
| WireGuard, L2TP and OpenVPN server | |
| OpenVPN client | |
| OpenVPN and IPsec site-to-site VPN | |
| One-click Teleport and Identity VPN | |
| Policy-based WAN and VPN routing | |
| DHCP relay | |
| Customizable DHCP server | |
| IGMP proxy | |
| IPv6 ISP support | |
| Ethernet | White: link/activity |
| SFP+ | White: link/activity |
| HDD | White: disk activity |
| Amber | disk error |
| RPS | Blue: ready |
| รหัสสินค้า (SKU) | UQT-UDM-SE |
| หมวดหมู่ | แอคเซสพอยต์ & Wi-Fi |
| ประเภทการจัดส่ง | จัดส่งสินค้าจริง |
