Name: TP-LINK ER707-M2 Omada Multi-Gigabit VPN Router
Brand: TP-Link
SKU: ER707-M2

รายละเอียดสินค้า

รุ่น / SKU	ER707-M2
IPv6	StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode
Omada App	Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management	• Omada Cloud-Based Controller Omada Hardware Controller Omada Software Controller
Cloud Access	Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning	Yes. Requires the use of Omada Cloud-Based Controller.
Management Features	• Automatic Device Discovery* Batch Configuration* Batch Firmware Upgrading* Intelligent Network Monitoring* Abnormal Event Warnings* Unified Configuration* Reboot Schedule*
System Requirements	Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10, MAC OS, NetWare, UNIX or Linux
Flash	128MB NAND
DRAM	1 GB DDR4
IPS Throughput	TCP: 208 Mbps;
DPI Throughput	TCP: 1823 Mbps;
WireGuard VPN Throughput	343Mbps
IPsec VPN Throughput	• ESP-SHA1-AES256: 673.3 Mbps
L2TP VPN Throughput	• Unencrypted: 1243.7 Mbps
SSL VPN Throughput	132.24 Mbps
Storage Temperature	-40–70 ℃ (-40–158 ℉)
Storage Humidity	5–90% non-condensing
Mobile Broadband	4G/3G modem for backup via USB port
Bandwidth Control	• IP/Port-based Bandwidth Control Guarantee & Limited Bandwidth
Interface	• 1× 2.5G RJ45 WAN Port 1× 2.5G RJ45 WAN/LAN Port 1× Gigabit SFP WAN/LAN Port 4× Gigabit RJ45 WAN/LAN Ports 1× USB 2.0 Port (Supports USB storage, and LTE backup with LTE dongle)
Network Media	• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
WAN Connection Type	• IPv4_Static IP IPv4_Dynamic IP IPv4_PPPOE IPv4_L2TP IPv4_PPTP IPv6_PPP IPv6_DHCPv6 IPv6_Static IP IPv6_6in4 IPv6_Pass-Through
Power Supply	12V/1.5A Adapter
PoE Budget	–
Max Power Consumption	14.2 W (with USB2.0 connected) 7.1 W (without USB2.0 connected)
NAT(PPPoE)	2347.14 Mbps / 2348.29 Mbps
Button	Reset Button
Protection	4 kV surge protection
VLAN	802.1Q VLAN
Fan Quantity	Fanless
Dimensions ( W x D x H )	8.9 × 5.2 × 1.4 in (226 × 131 × 35 mm)
Mounting	Rackmout, Desktop, or Wall Mount
NAT (Static IP)	2365.17 Mbps / 2364.45 Mbps
Certification	CE, FCC, RoHS
Package Contents	• ER707-M2 Power Adapter Quick Installation Guide Rackmount Kit
Environment	• Operating Temperature: 0–40 ℃ (32–104 ℉);
Operating Humidity	10–90% RH non-condensing
Access Control	Source/Destination IP Based Access Control
Filtering	• WEB Group Filtering § URL Filtering Web Security §
ARP Inspection	• Sending GARP Packets § ARP Scanning § IP-MAC Binding §
Attack Defense	• TCP/UDP/ICMP Flood Defense Block TCP Scan (Stealth FIN/Xmas/Null) Block Ping from WAN
Standards and Protocols	• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q， IEEE802.3bz TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP, WireGuard VPN
100BASE-TX	UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)
1000BASE-T	UTP category 5, 5e, 6 cable (Max 100 m)
2500BASE-T	UTP category 5, 5e, 6 cable (Max 100 m)
LED	PWR, SYS, SFP, USB, WAN (Speed, Link/Act), LAN (Speed, Link/Act)
Enclosure	Steel
UDP	161 Mbps
UDP	1272 Mbps
Concurrent Session	500,000
New Sessions /Second	6,000
NAT(DHCP)	2364.45 Mbps / 2366.04 Mbps
NAT (L2TP)	1308.86 Mbps / 974.10 Mbps
NAT (PPTP)	1236.27 Mbps / 1280.99 Mbps
ESP-SHA256-AES256	650.2 Mbps
ESP-SHA384-AES256	629.3 Mbps
ESP-SHA512-AES256	633.8 Mbps
Encrypted	561.0 Mbps
MAC Clone	Modify WAN/LAN MAC Address †
DHCP	• DHCP Server DHCPv6 PD Server (only in Standalone Mode) DHCP Options Customization DHCP Address Reservation Multi-IP Interfaces* Multi-Net DHCP*
IPTV	IGMP v2/v3 Proxy, Custom Mode, Bridge Mode
Advanced Routing	• Static Routing Policy Routing RIP (only in Standalone Mode) OSPF (only in Standalone Mode)
Load Balance	• Intelligent Load Balance Application Optimized Routing Link Backup (Timing § , Failover) Online Detection
NAT	• One-to-One NAT § Multi-Net NAT Port Forwarding Port Triggering § NAT-DMZ FTP/H.323/SIP/IPSec/PPTP ALG UPnP
Session Limit	IP-based Session Limit
IPsec VPN	• 100 IPSec VPN Tunnels LAN-to-LAN, Client-to-LAN Main, Aggressive Negotiation Mode DES, 3DES, SHA1, AES128, AES192, AES256 Encryption Algorithm IKEv1/v2 MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm NAT Traversal (NAT-T) Dead Peer Detection (DPD) Perfect Forward Secrecy (PFS)
PPTP VPN	• PPTP VPN Server PPTP VPN Clients (12) 60 Tunnels (Shared with L2TP) PPTP with MPPE Encryption
L2TP VPN	• L2TP VPN Server L2TP VPN Clients (12) 60 Tunnels (Shared with PPTP) L2TP over IPSec
OpenVPN	• OpenVPN Server OpenVPN Clients (6) 66 OpenVPN Tunnels*
WireGuard VPN	• 20 Tunnels
Web Authentication	• No Authentication Simple Password* Hotspot (Local User/Voucher/SMS/Radius) External Radius Server External Portal Server LDAP
Service	Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe)
Maintenance	• Web Management Interface Remote Management Export & Import Configuration SNMP v1/v2c/v3* Diagnostics (Ping & Traceroute) § NTP Synchronize § Port Mirroring CLI (only in Standalone Mode) Syslog Support
ระยะเวลารับประกัน	ตลอดอายุการใช้งาน (สิ้นสุด 3 ปีหลังผู้ผลิตประกาศหยุดผลิต)
